LLM Flax API context

With the new Grok 4 that has a huge context I thought it would be interesting to try feed it the Flax API at the start of any discussion about Flax code generation.

In theory it should help it to keep the code Flax only rather than hallucinate a lot of Unity calls, like these LLMs tend to due to the massive amount of Unity-based training data used.

So I downloaded:

Then created the following script that will generate flax_api_reference.txt, which can be dragged into the LLM chat.

The file gets quite large if all APIs are included, but you can just delete any HTML files that are not relevant.

I havent tested it much yet, but I did have a lot of issues with Unity code being inserted in my Flax code earlier, hopefully this can be useful to someone. :slight_smile:

import os
from bs4 import BeautifulSoup
import re

# Path to the downloaded api directory
api_dir = r"C:\Users\sinsro\Desktop\temp\flax\FlaxDocsHost-master\api"  # Adjust if needed
output_file = "flax_api_reference.txt"

def extract_content(file_path):
    filename = os.path.basename(file_path)
    with open(file_path, 'r', encoding='utf-8') as f:
        html = f.read()
    soup = BeautifulSoup(html, 'html.parser')

    content = soup.find('article', {'id': '_content'})
    if not content:
        return f"No extractable content in {filename}\n"

    text = ""

    # H1: Class/Struct/Enum name
    h1 = content.find('h1')
    if h1:
        page_title = h1.get_text(strip=True)
        text += f"{page_title}\n\n"

    # Summary/Description
    summary = content.find('div', class_='markdown level0 summary')
    if summary:
        summary_text = ' '.join([p.get_text(strip=True) for p in summary.find_all('p')])
        text += f"{summary_text}\n\n"

    # Inheritance
    inheritance_header = content.find('h5', string=re.compile(r'Inheritance'))
    if inheritance_header:
        inheritance_div = inheritance_header.find_next('div', class_='inheritance')
        if inheritance_div:
            inh_parts = [span.get_text(strip=True) for span in inheritance_div.find_all('span') if span.get_text(strip=True)]
            inh_text = ' > '.join(inh_parts)
            text += f"Inheritance {inh_text}\n\n"

    # Namespace
    namespace_header = content.find('h6', string=re.compile(r'Namespace'))
    if namespace_header:
        ns_a = namespace_header.find_next('a')
        ns_text = ns_a.get_text(strip=True) if ns_a else ''
        text += f"Namespace {ns_text}\n\n"

    # Assembly
    assembly_header = content.find('h6', string=re.compile(r'Assembly'))
    if assembly_header:
        asm_code = assembly_header.find_next('code')
        asm_text = asm_code.get_text(strip=True) if asm_code else ''
        text += f"Assembly {asm_text}\n\n"

    # Syntax
    syntax_header = content.find('h5', string=re.compile(r'Syntax'))
    if syntax_header:
        text += "Syntax\n\n"
        syntax_pre = syntax_header.find_next('pre')
        if syntax_pre:
            syntax_code = syntax_pre.get_text(strip=True)
            text += syntax_code.replace('\n', '\n') + "\n\n"

    # Sections like Fields, Properties, etc.
    sections = content.find_all('h3', id=lambda x: x and (x.startswith('fields') or x.startswith('properties') or x.startswith('methods') or x.startswith('extensionmethods') or x.startswith('interfaces')))
    for section in sections:
        section_title = section.get_text(strip=True)
        text += f"{section_title}\n\n"

        current = section.next_sibling
        while current and (not current.name or current.name != 'h3'):
            if current.name == 'h4':  # Member name
                member_name = current.get_text(strip=True)
                text += f"{member_name}\n"

                # Get the member container div
                member_container = current.find_next_sibling('div', class_='collapse in')
                if member_container:
                    # Summary
                    member_summary = member_container.find('div', class_='markdown level1 summary')
                    if member_summary and member_summary.get_text(strip=True):
                        member_desc = member_summary.get_text(strip=True)
                        text += f"{member_desc}\n"

                    # Declaration
                    decl_header = member_container.find('h5', string=re.compile(r'Declaration'))
                    if decl_header:
                        text += "Declaration\n"
                        decl_pre = decl_header.find_next('pre')
                        if decl_pre:
                            decl_code = decl_pre.get_text(strip=True)
                            decl_code_indented = decl_code.replace('\n', '\n')
                            text += f"{decl_code_indented}\n"

                    # Field/Property Value
                    value_header = member_container.find('h5', class_=['fieldValue', 'propertyValue'])
                    if value_header:
                        text += "Type\n"
                        value_table = value_header.find_next('table')
                        if value_table:
                            value_td = value_table.find('td')
                            value_text = value_td.get_text(strip=True) if value_td else ''
                            text += f"{value_text}\n"

                text += "\n"
            elif current.name == 'table':  # For namespaces or classes lists
                table_header = section.get_text(strip=True) if section else 'Table'
                text += f"{table_header}:\n"
                for row in current.find_all('tr'):
                    cells = [cell.get_text(strip=True) for cell in row.find_all(['th', 'td'])]
                    if cells:
                        text += "  " + " | ".join(cells) + "\n"
                text += "\n"
            current = current.next_sibling
        text += "\n"

    # Extension Methods (special handling if not caught above)
    ext_section = content.find('h3', id='extensionmethods')
    if ext_section:
        text += "Extension Methods\n\n"
        ext_divs = ext_section.find_next_siblings('div', class_=None)
        for div in ext_divs:
            if div.find('a', class_='xref'):
                ext_a = div.find('a', class_='xref')
                ext_name = ext_a.get_text(strip=True)
                text += f"{ext_name}\n"
                ext_summary = div.find('div', class_='markdown level1 summary')
                if ext_summary and ext_summary.get_text(strip=True):
                    ext_desc = ext_summary.get_text(strip=True)
                    text += f"{ext_desc}\n"
                text += "\n"

    # Clean duplicates
    lines = text.split('\n')
    clean_lines = []
    seen = set()
    for line in lines:
        stripped = line.strip()
        if stripped and stripped not in seen:
            seen.add(stripped)
            clean_lines.append(line)
    text = '\n'.join(clean_lines) + '\n\n'

    return text

def generate_api_reference():
    with open(output_file, 'w', encoding='utf-8') as f:
        # Get all html files, sort them alphabetically, skip index.html and toc.html
        all_files = []
        for root, dirs, files in os.walk(api_dir):
            for file in files:
                if file.endswith('.html') and file not in ('index.html', 'toc.html'):
                    all_files.append(os.path.join(root, file))
        all_files.sort(key=lambda x: os.path.basename(x))

        for file_path in all_files:
            f.write(extract_content(file_path))

# Run the generation
generate_api_reference()
print(f"API reference saved to {output_file}")

That repository is 5yrs old ‘legacy version of engine’. If you want to make a data file for RAG, it might be better extracting from main repo, or official document repository.

For file packaging, try look Repomix.

1 Like

By the way, about the size of context, Gemini 2.5 has 1M - about 4x larger than grok 4.

It makes much available to use CAG(Cache Augmented Generation)

Thanks, Repomix sounds like a good idea, it didnt work for me though (the online version), I just got an error message saying I could try to install it locally. For now using the script above works already though, so I didnt do that, I just updated to the latest API.

Meanwhile I have been testing the concept of seeding the context with the API overview a bit, and the AI went from being a total idiot just pushing Unity code and fantasy methods to actually being quite helpful.

Still a far way to go, both humans and LLMs need more Flax tutorials and community activity.

1 Like

It is wonderful to hear that your compiled documents works well.

Can you share the data file for the sake of the flax users?

Sure, here’s the latest Flax API and manual in an LLM friendly format, the format was reviewed and iterated by LLMs to make it optimal. Can probably massage them further, but its a start.

Just drag those in and ask the LLM to pay attention to them when generating code.

https://files.catbox.moe/em09k6.zip

Grok 4 does a pretty good job (especially if you emphasize it should review the files before replying), GPT O4-mini-high too, didnt try others so far.

1 Like

Sorry, I tried to download it later but the link doesn’t work. Does this file have an expiration date?

Well, I somehow sent the updated link to the wrong forum post, juggling too many balls in the air at once… Trying again, this is another file host, hopefully it wont expire so easily:

2 Likes

Thanks! It works great!

Tested with Gemini and locally with Qwen, SmolLM , Phi 3 and TinyLlama
